ABA Three Layers Biodegrade Film Blowing Machine

Basic Info.

Model NO.	SJ-50X2FM800
Machine Weight	4T
Certification	CE, ISO9001:2008
Motor Brand	Siemens Brand
Inverter	Delta Brand
Rewinder	Automatic Cutting and Change Roll
Power	3p/380V/415V/220V
Usefull	Make Shopping Bag. Packing Film etc.
Electrical Parts	Schneider
Die Head.	ABA Three Layers
Film Width	800/1000/1200/1500mm
Screw Material	Bimetalic High Speed Screw
Material	HDPE. LDPE,,Biodegrade, PLA
Speed	100-120kgs/H
Transport Package	Standard Wooden Box, etc.
Specification	CE, ISO
Trademark	SANBI
Origin	China
HS Code	8477301000
Production Capacity	100-120kgs/H

Product Description

HIGH SPEED ABA Three Layers Biodegrade Film Blowing Machine
Use:
The lines are designed developed by our corporation according to market need, they reach the advanced levels in the 90s, come up with analogous lines in home.
It is optimum designed on the trounds of preference of analogous lines in foreign and home.
SPECIFICATIONS

Model	ABA 800
Screw Diameter	Ф50×2
Screw Ratio L/D	30:1
Screw Speed	15-120r/min
Main Motor Power	15Kw×2
Extrusion Output	100-120kg/h
Range of Die	ABA Ф80
Single-sided Thickness of Film	0.01-0.10mm
Max. Folding Width of Film	800mm
Electric Total Capacity	50Kw
Overall Dimension	5000×3500×5000mm
Weight of Machine	4T
